  • Uniform and detail-oriented
  • No stripes & No noise
  • Collimated beam
  • Long distance indication
  • Low thermal resistance
  • High power conversion efficiency
  • Infrastructure alignment
  • Medical and beauty application
  • Indication and positioning
    This product is integrated by in-house manufactured & high-quality laser diode and is shielding with copper for better heat dissipation.
    Compared with traditional frequency doubles laser and LED, it enables to provide a higher peak power and lower power consumption, low wavelength drift with temperature and good reliability. It provides narrower emission angle without optical and thermal compensation, which allow to operate a wider range of environments.
    This product with laser diodes with smallsized, light, low price, long life, low power consumption and fast frequency response.
    It can be applied to infrastructure alignment,positioning, indication, inspection, machine vision and other fields for ideal invisible laser source.

Part Number  Wavelength(nm) Optical power(mW) Beam divergence(°) Description  Beaem spot Datasheet
VM-0405F-005M-GL-0A0 405士10 5士1 110  Φ7×L13.7 Line Download PDF
VM-0450B-002M-AL-0A0 450 2 - L50 × W50 x H57 Line Download PDF
VM-0808F-050M-GL-0A0 808士10 CW50;Pulse100 ≥130 Φ8×L11 Line, linewidth ≤2mm Download PDF
VM-0850B-006M-AL-0A0 850±2 6 - L13 x φ9 Line with 120±2° Download PDF
VM-0850F-025M-HL-0A0 850 25士1 1.2士0.1 Φ9×L11 Line, horizontal angle 155°~165° Download PDF
VM-0940C-080M-AL-0A0 940 80 - L10.5 x φ9 Line with 110° Download PDF
