Dot Shape Laser module
Date: 2021-12-09 13:56Page view:
Features
-
niform and detail-oriented
-
Collimated beam
-
Long distance indication
-
Manual beam spot adjustment
-
High power conversion efficiency
-
Low thermal resistant
|
Applications
-
Teaching and scene guidance
-
Infrastructure alignment
-
Lighting for stage performance
-
Medical and beauty application
-
Indication and positioning
|
Description
This product is integrated with imported and high-quality laser diodes and is shielding with copper for better heat dissipation.
Compared with traditional frequency doubles laser and LED, it enables to provide a higher peak power and lower power consumption, subtle wavelength shift with temperature and good reliability. It provides narrow emission angle without optical and thermal compensation, which allow various operation environments.
|
This product with laser diodes with small-sized, light, low price, long life,low power consumption, fast frequencyresponse and manual beam spot adjustment. |
 |
|
It can be applied to infrastructure alignment, positioning, indication, inspection, machine vision and other fields for ideal visible laser source. |
PRODUCT IDENTIFY
|
Part Number |
Wavelength(nm) |
Optical power(mW) |
Beam divergence |
Beaem spot |
Description（mm） |
Datasheet |
|
VM-0450C-026M-AD-0A0 |
450 |
26 |
≤0.8mrad |
dot |
M11.5(φ10.5) x L19.3 |
Download PDF |
|
VM-0520B-004M-AD-0A0 |
520 |
4 |
≤0.8mrad |
dot |
M11.5(φ10.5) x L19.3 |
Download PDF |
|
VM-0650B-003M-AD-0A0 |
650 |
3 |
≤0.8mrad |
dot |
M11.5(φ10.5) x L19.3 |
Download PDF |
|
VM-0850B-006M-AD-0A0 |
850 |
3 |
≤2mrad |
dot |
Φ6.5×L22 |
Download PDF |
|
VM-0850G-004M-AD-0A0 |
850 |
4 |
7±1mrad |
dot |
Φ6.5×10.5 |
Download PDF |
